配置說明
車架組
尺寸15.5,17.5,19.5,21.5"車架AlphaRedAluminumw/ABPRace,FullFloater,magnesiumEVOLink,oversizedpivotbearings,replaceablederailleurhanger,100mmtravel
前叉RockShoxRebaRLw/airspring,rebound,remotelockout,alloysteerer,100mmtravel
輪組
輪組BontragerRaceLiteDiscwheelsystem,28hole,centerlock,tubelessready外胎BontragerXR3Expert,26x2.2"
傳動系統
變速器ShimanoSLX,10speed前撥ShimanoSLX
後撥ShimanoSLX
曲柄ShimanoSLX,42/32/24
飛輪ShimanoHG811011-36,10speed
腳踏n/a
組件
坐墊BontragerEvoke2,chromolyrails座桿BontragerRhythmElite,31.6mm,zerooffset
把橫BontragerLowRiser,31.8mm,25mmrise,9degreesweep
把立BontragerRaceLite,31.8mm
頭管組FSAOrbitZ,1-1/8"semi-integrated,sealed
剎車系統AvidElixirRhydraulicdiscbrakes
附屬檔案n/a
其他Trekforkandshocksagmeter,Bontragershockpump
